Transient props and shouldForwardProp are styled components API let you filter out props that should not be passed to the underlying React node or DOM element. In this post we will see how we can create a type to automatically define transient props from the interface (of props) of a parent component.

Styled component propagate by default all the props passed to a component to the underlying React node or DOM element. The framework offers a couple of ways to avoid this behavior. The first one is Transient props. By using $ as a prefix of a prop name it will not be propagated. The second one is the shouldForwardProp. This is a fine-grained way to prevent the prop forward with a specific filter that acts on the name of the props. You can add it using the withConfig api or the shouldForwardProp prop as in the example below.

interface BigCardProps {
  big: boolean;
}

const PostCardContainer = styled.div<BigCardProps>`
  /// ...other css rules...

  /// usage of the "big" prop
  ${(props) => !props.$big && css` width: 48%; `}}

  /// ...other csss rules...
`;
PostCardContainer.shouldForwardProp = (prop: string) => prop !== "big";

Anyway, both these methods require a manual development specific on the prop names. In particular, it is very tedious when you have a parent component and its children are styled components that should receive the same props. However, you want to avoid forwarding them to the DOM (because their main purpose is styling/logic condition).
See, for example, the code below, where there is a parent component that calls a hook and uses a styled component as children to create an overlay effect. The StyledOverlay component receive all the props of the container component, and we want to:

• avoid the forward for zIndex and delay because they are not DOM attributes. This is why they are contained again in the StyledOverlayProps interface with the $ transient prop prefix.
• forward the onClick prop to the underling DOM element (and so we don't add the property to the StyledOverlayProps but we still pass it to the component).

interface StyledOverlayProps {
  $zIndex: number;
  $delay: string;
}

const StyledOverlay = styled.div<StyledOverlayProps>`
  position: fixed;
  top: 0;
  left: 0;
  width: 100%;
  height: 100%;
  z-index: ${(props) => props.$zIndex};
  background: rgba(0, 0, 0, 0.6);
  opacity: 0;
  animation: ${opacity} 0.25s linear ${(props) => `${props.$delay}`};
  animation-fill-mode: forwards;
  backdrop-filter: blur(4px);
`;

export interface OverlayProps {
  zIndex: number;
  delay: string;
  onClick: () => void;
}

export const Overlay: FC<OverlayProps> = ({ zIndex, onClick, delay }) => {
  useLockBodyScroll();

  return (
    <StyledOverlay
      $zIndex={zIndex}
      $delay={delay}
      onClick={onClick}
    />
  );
};

In the last couple of years, I felt in love with the TypeScript type system. It is so powerful and flexible that it allows you to write DSL with validation that other languages would dream of. A lot of colleagues still argue that this kind of knowledge on the specific part of TypeScript is useless, but I strongly disagree. Why? Because in this post, I will show you a practical application of the knowledge I acquired to solve the problem above. In particular, we want to avoid coding two different interfaces, but just creating a new one starting from the OverlayProps that adds the $ sign to the ones that should be transient props, and skips the other ones that are DOM attributes.

Implementation

Based on the description above, we want to define a TransientProps type that is able to:

• add the $ prefix to props that are not DOM attributes, and are defined by ourselves
• skip the DOM props in some way, because they should still be forwarded

To start the implementation, we need first to check some types exposed by React.
For our use case it will be useful the ComponentProps type. This utility type lets us extract the props of a React component received as generic parameter.
The other interesting type is React.JSX.IntrinsicElements. This is a type that declares which JSX elements are allowed/defined and their props. In the case of React DOM, these are the HTML tags.
So we can start to define some custom types. First a type to convert anything to a string, that we will call Stringify. Next a type that describe a possible DOMElement, that in our case will be React.JSX.IntrinsicElements or false, if we don't want to pass/we don't have the need to get the props of the underlying DOM node.

type Stringify<PropName> = PropName extends string ? PropName : never;
type DomElement = keyof React.JSX.IntrinsicElements | false;

So given a DomElement, we could have two cases:

• we want to remap all the properties received because none of them is related to the underlying DOM node
• we want to remap all the properties received expect the one related to the underlying node

We can create a type that we will call OmitDomProps, that we will use to select the properties to be remapped into transient props based on the condition above. In particular, if we don't have a DomElement defined (so it extends false), we will just return the CustomProps received. If we have a DomElement (so it is inside the React.JSX.IntrinsicElements interface), we will omit its prop from the original CustomProps interface

type OmitDomProps<CustomProps, Component extends DomElement> = Component extends false
        ? keyof CustomProps
        : keyof Omit<CustomProps, keyof ComponentProps<Component>>;

Now we are ready to create the TransientProps type. This type receives two generic parameters:

• the CustomProps interface for which we want to remap the properties as transient ones.
• the IntrinsicElements if needed to get the type of the underlying DOM element. If not passed it will have a default false value and all the props will become transient.

This type will use TypeScript mapped types to remap the properties of CustomProps received. The utility types created before are used to conditionally filter out DOM properties if needed. We can add our utility type to the styled-components module. In this way, thanks to module augmentation, we will have the TransientProps type exposed as it is a type from the framework itself.

// ...Other imports...
import React, { ComponentProps } from "react";

declare module "styled-components" {
  // ...Other needed types for defining styled components themes...

  type Stringify<PropName> = PropName extends string ? PropName : never;
  type DomElement = keyof React.JSX.IntrinsicElements | false;
  type OmitDomProps<CustomProps, Component extends DomElement> = Component extends false
          ? keyof CustomProps
          : keyof Omit<CustomProps, keyof ComponentProps<Component>>;

  export type TransientProps<CustomProps, Component extends DomElement = false> = {
    [Key in OmitDomProps<CustomProps, Component> as `$${Stringify<Key>}`]: CustomProps[Key];
  };
}

Below you can see Overlay component we saw above refactored with this new type. As you can see, no additional interface is needed to define the props of the component. In this case we are passing the div element to filter out the onClick prop (but as we mentioned before you can also skip the second generic parameter so that all the props will become transient).

export interface OverlayProps {
  zIndex: number;
  delay: string;
  onClick: () => void;
}

const StyledOverlay = styled.div<TransientProps<OverlayProps, "div">>`
  position: fixed;
  top: 0;
  left: 0;
  width: 100%;
  height: 100%;
  z-index: ${(props) => props.$zIndex};
  background: rgba(0, 0, 0, 0.6);
  opacity: 0;
  animation: ${opacity} 0.25s linear ${(props) => `${props.$delay}`};
  animation-fill-mode: forwards;
  backdrop-filter: blur(4px);
`;

export const Overlay: FC<OverlayProps> = ({ zIndex, onClick, delay }) => {
  useLockBodyScroll();

  return <StyledOverlay $zIndex={zIndex} onClick={onClick} $delay={delay} />;
};

Conclusion

I love the TypeScript type system. Its flexibility and rich feature set are so vast and intricate that you could spend years exploring all its quirks and perks. Remember: with great power comes great responsibility. The same goes for the TypeScript type system. So, make sure to read the documentation carefully before going off on a tangent .
